Knuckle Nail Plate / Tylok Plate
Cangzhoufutong Knuckle Nailplates are galvanised steel connectors with in-built, bent-up “knuckle” nails. These plates are ideal for many structural and non-structural timber jointing and timber protection uses.
Among the many uses of Knuckle Nailplates, the most common are jointing of wall frames together on-site, on-site splicing of timber beams, reinforcement of corners of boxes and bins, and reinforcement of bolted joints (eg Cable Truss)
FEATURES
Generally, Knuckle Nailplates will:
Provide a strong, economical and easy-to-use means of jointing timber together.
Protect timber from damage as they resist splitting due to drying of the timber, nailing near ends or other causes eg Bin Straps.
Also reduce timber damage by resisting the effects of impact loads such as from fork lift tyne strikes.
Distribute concentrated loads over a wider area, eg they increase the strength of bolted joints.
Material:
1mm G300 Z275 Galvanised Steel
Code | Width | Length | Code | Width | Length |
2T5 | 34mm | 60mm | 2T10 | 68mm | 60mm |
4T5 | 34mm | 120mm | 4T10 | 68mm | 120mm |
6T5 | 34mm | 180mm | 6T10 | 68mm | 180mm |
8T5 | 34mm | 240mm | 8T10 | 68mm | 240mm |
10T5 | 34mm | 300mm | 10T10 | 68mm | 300mm |
12T5 | 34mm | 360mm | 12T10 | 68mm | 360mm |
14T5 | 34mm | 420mm | 14T10 | 68mm | 420mm |
16T5 | 34mm | 480mm | 16T10 | 68mm | 480mm |
Coil T5 | 34mm | 15m | Coil T10 | 68mm | 15m |
Code | Width | Length | Code | Width | Length |
4T15 | 102mm | 120mm | 6T20 | 136mm | 180mm |
6T15 | 102mm | 180mm | 8T20 | 136mm | 240mm |
8T15 | 102mm | 240mm | 10T20 | 136mm | 300mm |
10T15 | 102mm | 300mm | 12T20 | 136mm | 360mm |
12T15 | 102mm | 360mm | 14T20 | 136mm | 420mm |
Coil T15 | 102mm | 15m | Coil T20 | 136mm | 15m |
Knuckle Nail Plate / Tylok Plate
Cangzhoufutong Knuckle Nailplates are galvanised steel connectors with in-built, bent-up “knuckle” nails. These plates are ideal for many structural and non-structural timber jointing and timber protection uses.
Among the many uses of Knuckle Nailplates, the most common are jointing of wall frames together on-site, on-site splicing of timber beams, reinforcement of corners of boxes and bins, and reinforcement of bolted joints (eg Cable Truss)
FEATURES
Generally, Knuckle Nailplates will:
Provide a strong, economical and easy-to-use means of jointing timber together.
Protect timber from damage as they resist splitting due to drying of the timber, nailing near ends or other causes eg Bin Straps.
Also reduce timber damage by resisting the effects of impact loads such as from fork lift tyne strikes.
Distribute concentrated loads over a wider area, eg they increase the strength of bolted joints.
Material:
1mm G300 Z275 Galvanised Steel
Code | Width | Length | Code | Width | Length |
2T5 | 34mm | 60mm | 2T10 | 68mm | 60mm |
4T5 | 34mm | 120mm | 4T10 | 68mm | 120mm |
6T5 | 34mm | 180mm | 6T10 | 68mm | 180mm |
8T5 | 34mm | 240mm | 8T10 | 68mm | 240mm |
10T5 | 34mm | 300mm | 10T10 | 68mm | 300mm |
12T5 | 34mm | 360mm | 12T10 | 68mm | 360mm |
14T5 | 34mm | 420mm | 14T10 | 68mm | 420mm |
16T5 | 34mm | 480mm | 16T10 | 68mm | 480mm |
Coil T5 | 34mm | 15m | Coil T10 | 68mm | 15m |
Code | Width | Length | Code | Width | Length |
4T15 | 102mm | 120mm | 6T20 | 136mm | 180mm |
6T15 | 102mm | 180mm | 8T20 | 136mm | 240mm |
8T15 | 102mm | 240mm | 10T20 | 136mm | 300mm |
10T15 | 102mm | 300mm | 12T20 | 136mm | 360mm |
12T15 | 102mm | 360mm | 14T20 | 136mm | 420mm |
Coil T15 | 102mm | 15m | Coil T20 | 136mm | 15m |
The package could be customized according to your requirements.
The package could be customized according to your requirements.
